CheriBSD: FreeBSD for CHERI-enabled platforms

CheriBSD is a Capability Enabled, Unix-like Operating System that extends FreeBSD to take advantage of Capability Hardware on Arm’s Morello and CHERI-RISC-V platforms. CheriBSD implements memory protection and software compartmentalization features, and is developed by SRI International and the University of Cambridge.

↫ CheriBSD website

This obviously raises the question – what exactly is CHERI? The FreeBSD Foundation has an article about this from 2023 providing more details.

CHERI extends existing architectures (Armv8-A, MIPS64 (retired), RISC-V, and x86_64 (in development)) with a new hardware type, the CHERI capability. In CHERI systems, all access to memory is via CHERI capabilities either explicitly via new instructions or implicitly via a Default Data Capability (DDC) and Program Counter Capability (PCC) used by instructions with integer arguments. Capabilities grant access to specific ranges of (virtual, or occasionally, physical) memory via a base and length, and can further restrict access with permissions, which are compressed into a 128-bit representation (64-bits for the address and 64-bits for the metadata). In memory and in registers, capabilities are protected by tags that are cleared when the capability data is modified by a non-capability instruction or if a capability instruction would increase the access the capability grants. Tags are stored separately from data and cannot be manipulated directly.

↫ Brooks Davis

CheriBSD brings this capability to anyone with compatible hardware, providing access to about 10000 pre-built memory-safe packages alongside more than 260000 pre-built memory-unsafe packages, as well as fully memory-safe versions of the KDE desktop, bhyve, and a ton of others. You can use both types of packages alongside one another, there’s a nice installer, and it basically seems like you’re using regular FreeBSD, just with additional complications, the biggest of which is, of course, the limited hardware support.
